MikroTik LAMP 5G R16 LAMPGM&RG520F-EU — 5G router

Sharh yozing

KOD: LAMPGM&RG520F-EU

Narx uchun biz bilan bog'laning

Sotuvda yo'q

Bizga savol bering

To‘lov turlari

Bizning afzalliklarimiz

Kafolat muddati 12 oy

SMS orqali xabardor qilish

Qaytarish va almashtirish – muammosiz

Turli to‘lov usullari

Eng yaxshi narx

BrendMikroTik

Tavsif
Texnik xususiyatlar
Fikrlar

MikroTik LAMP 5G R16 LAMPGM&RG520F-EU — 5G router

MikroTik LAMP 5G R16 LAMPGM&RG520F-EU — tarmoqni mobil aloqa orqali ulash uchun 5G router.

Modelning asosiy parametrlari: Gigabit Ethernet portlari: 1; LTE toifasi: 20 (DL: 2.0 Gbps; UL: 200 Mbps); Operatsion tizim: RouterOS v7; Protsessor yadrolari soni: 2; Protsessorning nominal chastotasi: 800 MHz; Operativ xotira: 512 MB.

O‘zbekistondagi loyiha uchun LAMP 5G R16 modelini kerakli interfeyslar va foydalanish sharoitlariga qarab tanlang. Jadvaldagi LAMPGM&RG520F-EU versiyasining aniq parametrlari uskunani tarmoqning boshqa qismlari bilan moslashtirishga yordam beradi.

Texnik xususiyatlar

Ishlab chiqaruvchi kodi	LAMPGM&RG520F-EU
Arxitektura	ARM 64bit
Protsessor	88F3720
Protsessor yadrolari soni	2
Protsessorning nominal chastotasi	800 MHz
Protsessor oqimlari soni	2
RouterOS litsenziya darajasi	3
Operatsion tizim	RouterOS v7
Operativ xotira	512 MB
Ma’lumot saqlash xotirasi hajmi	32 MB
Ma’lumot saqlash xotirasi turi	FLASH
Nosozliklar orasidagi o‘rtacha ishlash vaqti (MTBF)	25C da taxminan 200'000 soat
Sinovdan o‘tkazilgan muhit harorati	-40°C to 70°C
DC quvvat kirishlari soni	1 (PoE-IN)
Eng yuqori quvvat sarfi	10 W
Ulangan qurilmalarsiz eng yuqori quvvat sarfi	10 W
PoE orqali quvvat qabul qilish	802.3af/at
Sovutish turi	Passiv
PoE kirish kuchlanishi	12-56 V
3G toifasi	R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
3G diapazonlari	1 (2100 MHz) 5 (850 MHz) 8 (900 MHz)
LTE toifasi	20 (DL: 2.0 Gbps; UL: 200 Mbps)
Yuklab olish uchun MIMO (DL)	4x4
Yuborish uchun MIMO (UL)	2x2
LTE FDD diapazonlari	1 (2100 MHz) 3 (1800 MHz) 5 (850 MHz) 7 (2600 MHz) 8 (900 MHz) 20 (800 MHz) 28 (700 MHz) 32 (1500 MHz)
LTE TDD diapazonlari	38 (2600 MHz) 40 (2300 MHz) 41 (2500 MHz) 42 (3500 MHz) 43 (3700 MHz)
5G NSA FDD diapazonlari	1 (2100 MHz) 3 (1800 MHz) 5 (850 MHz) 7 (2600 MHz) 8 (900 MHz) 20 (800 MHz) 28 (700 MHz)
5G NSA TDD diapazonlari	38 (2600 MHz) 40 (2300 MHz) 41 (2500 MHz) 75 (1500 MHz) 76 (1500 MHz) 77 (3700 MHz) 78 (3500 MHz)
5G SA FDD diapazonlari	1 (2100 MHz) 3 (1800 MHz) 5 (850 MHz) 7 (2600 MHz) 8 (900 MHz) 20 (800 MHz) 28 (700 MHz)
5G SA TDD diapazonlari	38 (2600 MHz) 40 (2300 MHz) 41 (2500 MHz) 75 (1500 MHz) 76 (1500 MHz) 77 (3700 MHz) 78 (3500 MHz)
TAC kodi	86945405
Gigabit Ethernet portlari	1
1G Ethernet Reverse PoE (PoE-in) portlari	1
SIM slotlari soni	1 Modem (Micro SIM)
M.2 slotlari soni	1
eSIM qo‘llab-quvvatlashi	Ha
Sertifikatlash	CE, EAC, ROHS
IP himoya darajasi	67
